Podnožje AMD® AM4
Čipset AMD® B550
Format ploče ATX
Podržana memorija DDR4
Bluetooth Da
Podržani procesori - AMD AM4 podnožje 3rd Gen AMD Ryzen procesora
Memorija - 3rd Gen AMD Ryzen procesora - 4 x DIMM, Max. 128GB, DDR4 4600(O.C)/4400(O.C)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3466(O.C.)/3200/3000/2800/2666/2400/2133 MHz Un-buffered memoriju- Next Generation AMD Ryzen PRO procesora - 4 x DIMM, Max. 128GB, DDR4 5100(O.C)/4800(O.C.)/4600(O.C)/4400(O.C)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3466(O.C.)/3200/3000/2800/2666/2400/2133 MHz Un-buffered memoriju- Dual Channel Memory Architecture- OptiMem II- ECC Memory (ECC mode) podrška varira od CPU
Multi-GPU podrška - Podržava AMD 2-Way CrossFireX tehnologiju
Integrisana grafička karta Integrated Graphics Processor:- 1 x DisplayPort 1.2- 1 x HDMI 2.1(4K@60HZ)
Slotovi za proširenje 3rd Gen AMD Ryzen procesora- 1 x PCIe 4.0 x16 (x16 mode)AMD B550 Chipset- 1 x PCIe 3.0 x16 (x4 mode)- 3 x PCIe 3.0 x1
Skladište Maksimalno podržava 2 x M.2 slota i 6 x SATA 6Gb/s portova3rd Gen AMD Ryzen procesora:- 1 x M.2_1 podnožje 3, sa M key, tip 2242/2260/2280/22110 storage uređaja (SATA & PCIe 4.0 x4 mode)AMD B550 Chipset:- 1 x M.2_2 podnožje 3, sa M key, tip 2242/2260/2280/22110 storage uređaja (SATA & PCIE 3.0 x 4 mode)- 6 x SATA 6Gb/s port(s)- Podržava Raid 0, 1, 10
Mrežna karta - Intel I225-V 2.5Gb Ethernet- ASUS LANGuard
Zvučna karta ROG SupremeFX 8-Channel High Definition Audio CODEC S1220A- Dual OP Amplifiers- Impedance sense for front and rear headphone outputs- Podržava: Jack-detection, Multi-streaming, Front Panel Jack-retasking- High quality 120 dB SNR stereo playback output and 113 dB SNR recording input- Podržava i do 32-Bit/192kHz playback Audio Feature:- SupremeFX Shielding tehnologiju- Gold-plated jacks- Optical S/PDIF in port(s) na zadnjem panelu- Audio Shielding- Premium Japanese audio capacitors- Audio Cover
USB USB portovi sa zadnje strane ( Total 8 )- 2 x USB 3.2 Gen 2 port(s)(1 x Type-A +1 x USB Type-C)- 4 x USB 3.2 Gen 1 port(s)(4 x Type-A)- 2 x USB 2.0 port(s)USB portovi sa prednje strane ( Total 6 )- 2 x USB 3.2 Gen 1 port(s)- 4 x USB 2.0 port(s)
Konektori na zadnjoj strani - 1 x Intel I225-V 2.5Gb Ethernet- 1 x DisplayPort- 1 x HDMI- 2 x USB 3.2 Gen 2 (1 x Type-A+1 x USB Type-C)- 4 x USB 3.2 Gen 1- 2 x USB 2.0- 1 x Optical S/PDIF out- 1 x BIOS FlashBack Button(s)- 5 x Gold-plated audio jacks
Interni konektori - 1 x CPU Fan connector(s)- 1 x CPU OPT Fan connector(s)- 3 x Chassis Fan connector(s)- 1 x AIO_PUMP connector- 1 x AAFP connector- 2 x Aura RGB Strip Header(s)- 1 x Addressable Gen 2 header(s)- 1 x USB 3.2 Gen 1(up to 5Gbps) konektor podržava dodatna 2 USB 3.2 Gen 1 port(s)- 2 x USB 2.0 konektora podržavaju dodatna 4 USB 2.0 port(s)- 1 x M.2 podnožje 1 sa M key, tip 2242/2260/2280/22110 storage uređaja (SATA & PCIe 4.0 x4 mode)- 1 x M.2 podnožje 2 sa M key, tip 2242/2260/2280/22110 storage uređaja (SATA & PCIE 3.0 x 4 mode)- 6 x SATA 6Gb/s connector(s)- 1 x Thunderbolt header(s)- 1 x 24-pin EATX Power connector(s)- 1 x 8-pin ATX 12V Power connector(s)- 1 x 4-pin ATX 12V Power connector(s)- 1 x System panel(s)- 1 x Thermal sensor connector(s)- 1 x Clear CMOS jumper(s)
BIOS - 256 Mb Flash ROM, UEFI AMI BIOS
Boja Crna
Prava potrošača Zagarantovana sva prava kupaca po osnovu zakona o zaštiti potrošača
