Osnovne karakteristike

Procesorsko ležište (socket) - Intel 1700

Čipset - Intel Z790

Tip memorije - DDR5

Memorijski slotovi - 4

Podržane memorije - 6.000MHz (O.C.), 5.800MHz (O.C.), 6.200MHz (O.C.), 4.800Mhz, 6.400MHz (O.C.), 5.200Mhz, 5.000Mhz, 5.600MHz, 5.400MHz, 6.600MHz (O.C.), 6.800MHz (O.C.), 7.000MHz (O.C.), 7.200MHz (O.C.), 7.400MHz (O.C.), 7.600MHz (O.C.), 7.800MHz+ (O.C.), 8.000MHz+ (O.C.)

Maksimalna ukupna memorija - 192GB

Ostale osobine - Podrška za Unbuffered ECC memoriju, Podrška za Extreme Memory Profile (XMP), Podrška za non-ECC UDIMM memory, Dual Channel, ASUS Enhanced Memory Profile II (AEMP II)

PCI Express x16 slot - 2x PCI Express 5.0

PCI Express x4 slot - 1x PCI Express 4.0

SATA priključci (ukupno) - 4

SATA priključci - SATA III 6Gbps

Broj M.2 slotova - 5

RAID - RAID 0, RAID 1, RAID 5, RAID 10

Žična mreža (LAN) - 2.5GBase-T (Gigabit)

Wi-Fi - Da

Wi-Fi standard - Wi-Fi 7 (802.11be)

Bluetooth - Da

Bluetooth verzija - 5.4

Broj kanala - 7.1

Model - ROG SupremeFX

Napomena - Jack-detection, Multi-streaming, Front Panel Jack-retasking, Premium audio capacitors, SupremeFX Shielding, Gold-plated jacks

Thunderbolt - 2x Thunderbolt 4

Broj HDMI priključaka - 1

Ukupno USB priključaka - 10

USB-A priključci - 5x USB 10Gbps (3.2 Gen 2)

USB-C priključci - 1x USB 10Gbps (3.2 Gen 2)

RJ-45 (LAN) - 1

Audio - 5x Gold-plated audio jacks

Ostali priključci - Clear CMOS button(s), BIOS Flashback taster, 1 x optical S/PDIF, 1x Wi-Fi Module

Naponski priključci - 2x 8 pin 12V Power Connector, 1 x 24 pin Main Power connector, 1x 8-pin PCIe power connector

USB-A - 2 x podrška za 4 USB 2.0 porta, 2 x podrška za 4 USB 5Gbps porta

USB-C - 1 x podrška za 1 USB 5Gbps port

Audio - 1x Front panel header

Ostali priključci - 4 x SATA 6Gb/s, 1 x 4-pin AIO Pump header, 1 x 4-pin CPU OPT Fan header, 1 x 10-1 pin System Panel header, 1 x 4-pin CPU Fan header, 3 x Addressable Gen 2 headers, 4 x 4-pin Chassis Fan headers, 1 x AURA RGB header, 1 x Thermal Sensor header, 5 x M.2, 1 x CPU Over Voltage jumper, 1 x FlexKey button, 1 x W_PUMP+ header, 1 x Start button, ReTry taster, 1 x Alteration Mode Switch, 1x 2-pin water in header, 1x 3-pin water flow header, 1x 2-pin water out header

Napomena - Za iskorišćavanje određenih internih konektora potrebni su dodatni bracket-i ili priključci na kućištu

Podržane tehnologije - SafeSlot, SafeDIMM, Extreme Engine Digi+, AI Cooling II, ProCool II

Format - ATX

Dimenzije - 305mm x 244mm

Stanje - Nekorišćeno

Reklamacioni period - 36 meseci
