Osnovne karakteristike

Procesorsko ležište (socket) - AMD AM5

Čipset - AMD X870E

Grafika - Upotreba grafike iz procesora

Tip memorije - DDR5

Memorijski slotovi - 4

Podržane memorije - Podržava DDR5 memorije do 9.600+MT/s (O.C.)

Maksimalna ukupna memorija - 256GB

Ostale osobine - Podrška za non-ECC UDIMM memory, Podrška za ECC UDIMM memory, Dual Channel, Podrška za AMD EXTended Profiles for Overclocking (EXPO), ASUS Enhanced Memory Profile (AEMP), NitroPath DRAM Technology, Podrška za DIMM Fit i DIMM Fit Pro

PCI Express x16 slot - 2x PCI Express 5.0 (x16 ili x8/x8 modovi)

PCI slot - 2

SATA priključci (ukupno) - 4

SATA priključci - SATA III 6Gbps

Broj M.2 slotova - 5

Podržani M.2 formati - 1x 2242 / 2260 / 2280 / 22110 (podrška za PCIe 5.0 x4 mod), 1x 2242 / 2260 / 2280 (podrška za PCIe 5.0 x4 mod), 2x 2242 / 2260 / 2280 (podrška za PCIe 4.0 x4 mod), 1x 2230 (podrška za PCIe 4.0 x2 mod)

RAID - RAID 0, RAID 1, RAID 10, RAID 5

Žična mreža (LAN) - 5GBase-T (Gigabit), 10GBase-T (Gigabit)

Model - Realtek

Wi-Fi - Da

Wi-Fi standard - Wi-Fi 7 (802.11be), MediaTek Wi-Fi 7 MT7927

Bluetooth - Da

Bluetooth verzija - 5.4

Broj kanala - 7.1

Model - Realtek ALC4082 Codec

Napomena - Jack-detection, Multi-streaming, Front Panel Jack-retasking, Premium audio capacitors, Podrška za S/PDIF izlaz, SupremeFX Shielding, Supports up to 32-Bit/384 kHz playback, Gold-plated jacks, ESS ES9219 QUAD DAC, High quality 120dB SNR stereo playback output and 110dB SNR recording input, Impedance sense for front and rear headphone outputs

DisplayPort priključci - Da preko USB-C

Broj HDMI priključaka - 1

HDMI priključci - 1x HDMI 2.1

Ukupno USB priključaka - 11

Ukupno USB-C priključaka - 5

USB-A priključci - 6x USB 10Gbps (3.2 Gen 2)

USB-C priključci - 2x USB 40Gbps (USB 4), 3x USB 10Gbps (3.2 Gen 2)

RJ-45 (LAN) - 2

Audio - 2x 3.5mm, 1x S/PDIF optički

Ostali priključci - BIOS Flashback taster, 1 x Wi-Fi Module, Clear CMOS button(s)

Naponski priključci - 2x 8-pin +12V CPU Power connectors, 1 x 24-pin Main Power connector, 1x 8-pin PCIe power connector

USB-A - 2 x podrška za 4 USB 5Gbps porta, 3 x podrška za 6 USB 2.0 porta

USB-C - 2 x podrška za 1 USB 20Gbps port

Audio - 1x Front panel audio

Ostali priključci - 4 x SATA 6Gb/s ports, 1 x 4-pin AIO Pump header, 1 x 4-pin CPU OPT Fan header, 1 x 10-1 pin System Panel header, 1 x 4-pin CPU Fan header, 1 x Thermal Sensor header, 4 x 4-pin Chassis Fan headers, 1 x Start button, 1 x W_PUMP+ header, 1x Alteration PCIe Mode Switch, 1 x FlexKey button, 1x LN2 Mode jumper, 1 x AIO Q-Connector, 5 x M.2 slots (Key M), 3 x Addressable Gen2 headers, 1 x ReTry button

Napomena - Za iskorišćavanje određenih internih konektora potrebni su dodatni bracket-i ili priključci na kućištu

Podržane tehnologije - AURA Sync, LANGuard, Armoury Crate, Q-Design, AMI UEFI BIOS, WinRAR, Extreme Engine Digi+, ROG CPU-Z, FlexKey, Extreme OC Kit, DriverHub, Asynchronous Clock, ASUS Thermal Solution, ASUS EZ DIY

Format - ATX

Dimenzije - 305mm x 244mm

Pakovanje - 1 x Quick Start Guide, 1 x ASUS WiFi Q-Antenna, 4 x SATA 6Gb/s kabl, 1 x DDR5 fan holder, 1 x Q-connector, 3 x M.2 Q-Slide package, 1 x ROG stickers, 1 x ROG Bottle Opener, 1 x ROG assistant fan (60mm), 1 x Screw package for cooling kit, 1 x Thermal pad for M.2 22110, 5 x M.2 backplate rubber packages, 1 x ROG VIP card

Reklamacioni period - 36 meseci
